Specification
Specification
- Built-in safety check valves.
| Model | MS105C | MS125C | MS150C | MS200C |
|---|---|---|---|---|
| Piston Stroke (mm) | 20 | 25 | 30 | 35 |
| Piston Area - Push Side (cm²) | 84 | 120 | 174 | 312 |
| Piston Area - Pull Side (cm²) | 79 | 113 | 160 | 290 |
| Max. Draw Bar Pull Pull side KN (kgf) | 29 (2957) | 42 (4283) | 60 (6118) | 108 (11013) |
| Max. Operating Pressure MPa Pull side MPa (kgf/cm²) | 4.0 (40.8) | 4.0 (40.8) | 4.0 (40.8) | 4.0 (40.8) |
| Total Leakage (l/min) | 0.8 | 0.8 | 0.8 | 0.8 |
| Max. Speed (r.p.m.) | 6000 | 6000 | 5500 | 5500 |
| Weight (kg) | 7.6 | 10.5 | 14 | 22.5 |
| Moment of Inertia N.m (kgf.m²) | 0.0125 | 0.022 | 0.047 | 0.097 |
Dimensions
- Draw bar pull force: Pressure 4.0MPa(40.8 kg/cm²)
- Total leakage: Pressure 3.0MPa(30.6 kg/cm²) and oil temperture 50°C
- Proximity switch: Model BES516-329-E4-Y9BALLUFF ) DC12/24V 200mA NPN
| Model | MS105C | MS125C | MS150C | MS200C |
|---|---|---|---|---|
| A | 105 | 125 | 150 | 200 |
| B | 20 | 25 | 30 | 35 |
| C | 135 | 160 | 190 | 245 |
| D | 100 | 130 | 130 | 145 |
| E | 80 | 110 | 110 | 120 |
| F | 30 | 35 | 45 | 55 |
| G | 21 | 25 | 31 | 37 |
| H | M20x2.5 | M24x3.0 | M30x3.5 | M36x4.0 |
| J | 35 | 44 | 45 | 60 |
| K | 252 | 260 | 269 | 288 |
| L | 163 | 163 | 163 | 166 |
| M | 89 | 97 | 106 | 122 |
| N | 152 | 160 | 169 | 185 |
| P (Max) | 45 | 51 | 56 | 69 |
| P (Min) | 25 | 26 | 26 | 34 |
| Q | 6-M10x20 | 6-M12x24 | 12-M12x24 | 12-M16x30 |
| R | 158 | 166 | 175 | 189 |
| S | 23 | 23 | 23 | 28 |
| T | 41 | 41 | 41 | 46 |
