TF series CNC Torsion Spring Machine
TF-320
Feature Of Product
1. Shaft winding system makes consistent diameter, particularly fits softer wire coiling, like magnetic wire or nickel chromium wire.
2. With tool stamping and bending, spring angle is consistent and more accurate than touch probe; meanwhile the high productivity is suitable for mass production.
3. Pitch is controlled by servo which makes set up easier and shortens set up time.
Specification
| Item | Specification |
|---|---|
| Wire diameter(steel wire) | Ø0.4~2.0 mm |
| MAX. O.D. | Ø25 mm |
| Axis | 3 axis |
| Winding direction | Left hand/ right hand |
| Machine dimension(W/L/H) | 1350x1350x1650(mm) |
| Machine net weight | 850kg |
