Die Casting Machine
Die Casting Machine
DC-150V3C
The EVERGREAT YOTA DC-105V3C Die Casting Machine is a small model, yet features compact, high speed response and production. The DC-150V3C provides 150 tons of clamping force 730 x 730 mm die platen sizes. Its injection speed reaches 7 M/sec. The front platen and C-shaped frame are one-piece fabricated to ensure accurate alignment of the injection center. High performance hydraulic system also features energy savings. The machine is equipped with a personified controller, that is easy to learn and operate. Also, it allows the operator to check the operation status at any time.
Specification
| Clamping force | 150 Ton |
| Die height | 200-500 mm |
| Tie bar distance | 465 x 465 mm |
| Max. weight of shot | 1.64 kg |
| Max. casting area | 426 cm² |
| Electricity | 15 kw |
